K080
| ???? ????? | ?????? ?????? | ??????????? |
| ?????? ?????? | 0.1 m/sec | 0.3 ft/sec |
| ???? ???? ??????? | -30℃~+80℃ | -22℉~+76℉ |
| ???? ??? | 350 bar | 5000 p.s.i. |
| ????? ????? | μmRa | μmRt | μinClA | μinRMS |
| ??? ????? ??????????Φd1 | 0.1<>0.4 | 4 max | 4<>16 | 5<>18 |
| ??? ??? ????ΦD1 | 1.6 max | 10 max | 63 max | 70 max |
| ??? ???? ????L1 | 3.2 max | 16 max | 125 max | 140 max |
| ??????? ???? ????? | |
| ???? ???? ????≤ S mm | 5.2 |
| ???? ?????? ?? ????? C mm | 2.1 |
| ???? ??? ??? ?????? r1 mm | 0.4 |
| ??????? | Φd1 | ΦD1 | ΦD2 | L1 mm |
| ?????? ?????? | f8 | H10 | H8 | +0.3 -0 |
????? ??????
?????? ? 080 ??????-?????? ????? ?? ??????? ??????? ????????????.
????? ?????? ?? ??? ????? ?? ????? ?????? ????????? ?????? ??????? ??????01 ? ????? ?? ???? ??????? ???? ????? ??? ????? ??????.
???? ??????
???????? ???????
| Фd1 | ФD1 | L1 | PART No. |
| 60 | 70 | 5 | K0800600 |
| 70 | 80 | 5 | K0800700 |
| 75 | 85 | 5 | K0800750 |
| 80 | 90 | 5.0 | K0800800 |
| 90 | 100 | 5.0 | K0800900 |
| 95 | 105 | 5.0 | K0800950 |
| 100 | 110 | 5.0 | K0801000 |
| 105 | 115 | 5.0 | K0801050 |
| 110 | 120 | 5.0 | K0801100 |
| 115 | 125 | 5.0 | K0801150 |
| 120 | 130 | 5.0 | K0801200 |
| 125 | 135 | 5.0 | K0801250 |
| 130 | 140 | 5.0 | K0801300 |
